UBIQUITI UniFi AC HD (UAP-AC-HD) 802.11ac Wave 2 Enterprise Wi-Fi Access Point
UBIQUITI UniFi AC HD, UAP-AC-HD, 1733 Mbps Wave2 AP/Hotspot 2,4/5 GHz, 802.11 a/b/g/n/ac/ac-wave2, 2 x Gbit LAN, 4x4 MU-MIMO - indoor, single pack
| Price exc. VAT: | Price inc. VAT: | For orders (total sum): |
| 241.60£ | 289.92£ | >0£ |
| 239.39£ | 287.27£ | >300£ |
| 237.17£ | 284.60£ | >1000£ |
Features:
Deploy the UniFi AC HD AP in high-density environments requiring maximum wireless performance. The UniFi AC HD AP features simultaneous, dual-band, 4x4 MU-MIMO technology and convenient 802.3at PoE+ compatibility.
Easy Mounting
Its sleek design seamlessly integrates into any environment (all accessories included) and is compatible with existing UAP-AC-PRO mounts.
LED
Unique LED provisioning ring provides administrator location tracking and alerts for each device.
Dual Gigabit Ethernet
The UniFi AC HD AP offers a secondary port available for bridging.
Superior Processing Power
The UniFi AC HD AP is capable of complex operations (guest control, filtering, and other resource-intensive tasks) that may slow down a lesser-equipped AP.
Power over Ethernet (PoE)
Includes PoE functionality. Each single-pack includes a PoE adapter.
PoE Standard
The UniFi AC HD AP is compatible with an 802.3at PoE+ compliant switch. We recommend powering your UniFi devices with a UniFi PoE Switch (sold separately).
UniFi PoE Switch
Available in 8, 16, 24, and 48-port versions with multiple power output options, the UniFi PoE Switch conveniently offers auto-sensing IEEE 802.3af PoE/802.3at PoE+.
Specification:
| UAP-AC-HD | |
|---|---|
| Dimensions | 220 x 220 x 48.1 mm |
| Weight with Mounting Kits |
700 g (24.7 oz) 830 g (29.3 oz) |
| Networking Interface | (2) 10/100/1000 Ethernet Ports |
| Ports | (2) Ethernet RJ45, (1) USB Type C |
| Buttons | Reset |
| Antennas | (2) 2.4G internal single band antennas, dual polarity (2) 5G internal single band antennas, dual polarity |
| Wi-Fi Standards | 802.11a/b/g/n/ac/ac-wave2 |
| Power Method | PoE 802.3at |
| Power Supply | PoE Injector 48VDC -0.5A Gigabit |
| Maximum Power Consumption | 17W |
| Max TX Power | 25 dBm |
| BSSID | 4 Per Radio |
| Power Save | Supported |
| Wireless Security | WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) |
| Certifications | CE, FCC, IC |
| Mounting | Wall/Ceiling (Kits Included) |
| Operating Temperature | -10 to 70° C (14 to 158° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Advanced Traffic Management | |
| VLAN | 802.1Q |
| Advanced QoS | Per-User Rate Limiting |
| Guest Traffic Isolation | Supported |
| WMM | Supported |
| Concurrent Clients | 500+ |
| Supported Data Rates (Mbps) | |
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11n | 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40) |
| 802.11ac | 6.5 Mbps to 1.7Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80) |
| 802.11b | 1, 2, 5.5, 11 Mbps |
| 802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
