UBIQUITI Power Supply with UPS and PoE, EdgePower 24V (EP-24V-72W)
Order code:
EP-24V-72W
Quick code:
#2094
EAN:
0817882027915
UPS device with dual PoE output ports. You can receive alerts in the event of a power outage, and the EP-24V-72W offers a 12V lead acid battery input (optional) for redundancy if the AC input fails over
| Price exc. VAT: | Price inc. VAT: | For orders (total sum): |
| 117.50£ | 141.00£ | >0£ |
| 116.42£ | 139.70£ | >300£ |
| 115.35£ | 138.42£ | >1000£ |
Features:
Protect your WISP site against power loss with the EdgePower EP-24V-72W or EP-54V-72W, a convenient UPS device with dual PoE output ports. You can receive alerts in the event of a power outage, and the EP-24V-72W or EP-54V-72W offers a 12V lead acid battery input (optional) for redundancy if the AC input fails over.
EdgePower 24V
• 24 VDC Output
• Dual 24 VDC Passive PoE Output
• AC Input
• Optional 12V Battery Input
Specification:
| Dimensions | 192 x 43.7 x 115 mm (7.559 x 1.72 x 4.528") |
| Weight | 650 g (1.43 lb) |
| Interfaces Networking Management |
(2) 10/100 Mbps RJ45 Ports Ethernet In-Band |
| PoE Output | (2) 24VDC Passive PoE (Pins 4, 5+; 7, 8-) |
| DC Output | 24V, 3A |
| Power Method AC Input Battery Input |
100-240VAC, 50-60 Hz, Universal Input DC Terminal Block |
| Power Supply AC Input Battery Input |
AC/DC 72W 12VDC Lead Acid Battery* |
| Max Power Consumption System Output |
2W 72W |
| LEDs System RJ45 Data Ports |
Status PoE; Link/Activity |
| ESD/EMP Protection | Air: ± 12 kV, Contact: ± 12 kV |
| Operating Temperature | 0 to 40° C (32 to 104° F) |
| Operating Humidity | 10 to 90% Noncondensing |
| Certifications | CE, FCC, IC |
