UBIQUITI Ethernet Surge Protector, Gen2 (ETH-SP-G2)
Ubiquiti ETH-SP Outdoor Ethernet Surge Protector with Gigabit LAN and 802.3af PoE support
|Price exc. VAT:||Price inc. VAT:||For orders (total sum):|
ESD Protection for Outdoor High-Speed Networks
Introducing the next generation Ethernet Surge Protector, model ETH-SP-G2, from Ubiquiti Networks. The ETH-SP-G2 is a cost-effective solution for protecting outdoor Ethernet devices from damaging electrostatic discharge and surges. Since all Ubiquiti® airMAX® devices already have robust ESD protection built in, adding the ETH-SP-G2 to the installation
provides an additional layer of protection to the network.
The ETH-SP-G2 is engineered to protect Power‑over‑Ethernet (PoE) or non-PoE devices with connection speeds of up to 1 Gbps. Two passive, surge-protected RJ45 connections provide maximum equipment compatibility.
Ideal for WISP Networks
All Ubiquiti airMAX devices are equipped with ESD protection. However, to protect outdoor devices, and to meet certain local code requirements, installing the ETH‑SP-G2 is essential.
For example, to guard against costly service calls, and to help your subscriber installations meet code requirements, install two ETH-SP-G2 devices: one near the CPE, and the other at the entry point to the building. Damaging ESD attacks and surges will be absorbed by the ETH-SP-G2 devices and safely discharged into the ground.
Additional ESD Protection
All Ubiquiti® airMAX® devices are equipped with built-in ESD protection, so the ETH‑SP adds another layer of protection to your outdoor, high-speed network.
Plug and Play Installation
Connect the ground and Ethernet cables in between your network devices.
Dimensions: 91 x 61 x 32.5 mm (3.58 x 2.4 x 1.28")
Weight: 80 g (2.82 oz)
Interface Connections: (2) RJ45 Female Connectors
ESD/EMP Protection: Absorbing Transient Current with Response to Surge Voltage from 100V/s to 1kV/μs
DC Spark-Over Voltage: 90V @ 100V/s
Maximum Impulse Spark-over Voltage: 700V @ 1kV/μs
Discharge Current: 10kA+
Maximum Insulation Resistance: 1G ohm @ 50V
Maximum Capacitance: 1.0 pF @ 1 MHz
Data Line Protection: RJ45 10/100/1000 Ethernet
IEEE 802.3af PoE Support: Yes
Shock and Vibration Certification: ETSI300-019-1.4 Standard
Operating Temperature: -30 to 65° C (-22 to 149° F)
Operating Humidity: 10 to 90% Noncondensing
