UBIQUITI 2.4 GHz High-Performance airMAX® ac Bridge with Dedicated Wi-Fi Management (PBE-2AC-400)
Incorporating a dish reflector design with proprietary airMAX® ac technology, the PowerBeam® AC is ideal for CPE deployments requiring maximum performance. 18 dBi Gain, Output Power: 27 dBm, 1x Gigabit LAN port, 330+ mbps Throughput, 20+ km
| Price exc. VAT: | Price inc. VAT: | For orders (total sum): |
| 88.20£ | 105.84£ | >0£ |
| 87.39£ | 104.87£ | >300£ |
| 86.58£ | 103.90£ | >1000£ |
Features:
The latest generation of airMAX® CPE (Customer Premises Equipment), the PowerBeam® 2AC, with dedicated Wi-Fi management.
Improved Noise Immunity
The PowerBeam 2AC directs RF energy in a tighter beamwidth. With the focus in one direction, the PowerBeam 2AC blocks or spatially filters out noise, so noise immunity is improved. This feature is especially important in an area crowded with other RF signals of the same or similar frequency.
Integrated Design
Ubiquiti’s InnerFeed® technology integrates the radio into the feedhorn of an antenna, so there is no need for a cable. This improves performance because it eliminates cable losses.
Featuring high performance and innovative design, the PowerBeam 2AC is versatile and cost‑effective to deploy.
Management Wi-Fi Radio
The PowerBeam® AC integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.
Improved Mounting and Surge Protection
Featuring enhanced protection against ESD events, the PowerBeam® AC offers a more robust mount with a convenient lifting loop or handle.
Integrated Radio Design
Ubiquiti’s InnerFeed® technology integrates the radio into the feedhorn of an antenna, so there is no need for cables to connect the radio to the antenna. This improves performance because it eliminates cable losses.
Plug and Play Installation
The PowerBeam® AC requires no tools for assembly; only a single wrench is required for pole-mounting.
Performance Breakthrough
airMAX® ac products offer improved latency, noise immunity, scalability and significantly increased throughput performance.
Superior Processing
Ubiquiti's airMAX® engine with custom IC dramatically improves TDMA latency and network scalability. The custom silicon provides hardware acceleration capabilities to the airMAX scheduler, to support the high data rates and dense modulation used in airMAX ac technology.
Incredible Antenna “Beam” Performance
The form factor of the PowerBeam® AC features the highest gain for its size. The PowerBeam AC’s excellent beam directivity provides the best performance in high-noise environments.
Now with airOS®8
airOS®8 provides powerful features, including airMAX® ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.
Specification:
Operating Frequency (MHz): 2412-2472
Management Radio (MHz): 5150-5250
Dimensions (with Radome): 420 x 420 x 289 mm; (16.54 x 16.54 x 11.38")
Weight (Mount Included): 1.795 kg (4.809 lbs)
Power Supply: 24V, 0.5A Gigabit PoE Adapter (Included)
Max. Power Consumption: 7.5W
Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return)
Supported Voltage Range: 22 to 26VDC
Gain: 18 dBi
Networking Interface: (1) 10/100/1000 Ethernet Port
Processor Specs: MIPS 74Kc
Memory: 64 MB
LEDs: Power, Ethernet, (4) Signal Strength
Channel Sizes:
PtP Mode - 10/20/40 MHz
PtMP Mode - 10/20/40 MHz
Enclosure Characteristics:
Antenna Feed - Outdoor UV Stabilized Plastic
Dish Reflector - Powder-Coated SPCC
Mounting: Pole-Mounting Kit (Included)
Wind Loading: 342.5 N @ 200 km/h (77 lbf @ 125 mph)
Wind Survivability: 200 km/h (125 mph)
ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
Operating Temperature: -40 to 70° C (-40 to 158° F)
Operating Humidity: 5 to 95% Noncondensing
RoHS Compliance: Yes
Salt Fog Test: IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5
Vibration Test: IEC 68-2-6
Temperature Shock Test: IEC 68-2-14
UV Test: IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4
Wind-Driven Rain Test: ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5
Certifications: CE, FCC, IC
