UBIQUITI Gigabit Router with SFP, EdgeRouter™ 6P (ER-6P)
6-Port Gigabit Router with 1 SFP Port, 4-Core 1 GHz processor, 1 GB DDR3 RAM, 3.4 million packets per second routing performance, 5x 24V Passive PoE Ports, Rack-Mountable (with optional kit)
| Price exc. VAT: | Price inc. VAT: | For orders (total sum): |
| 167.50£ | 201.00£ | >0£ |
| 165.96£ | 199.15£ | >300£ |
| 164.42£ | 197.30£ | >1000£ |
Features:
Advanced Routing
Technology for the Masses
Ubiquiti Networks introduces the EdgeRouter™ 4 and EdgeRouter 6P, the next generation of routers for the EdgeMAX® platform. EdgeRouters combine carrier-class reliability with
enterprise-level features in a compact and affordable unit.
The EdgeRouter 4 and EdgeRouter 6P offer Gigabit Ethernet ports and an SFP port for a fiber link. The EdgeRouter 6P also offers five configurable PoE ports to power
airMAX® products.
The EdgeRouter 4 and EdgeRouter 6P are each capable of routing up to 3.4 million packets per second. The EdgeRouter 4 has a line rate of 4 Gbps, while the EdgeRouter 6P has a line rate of 6 Gbps.
Powered by a proprietary and intuitive graphical interface, EdgeOS®, EdgeRouters can easily be configured for routing, security, and management features required to efficiently run
your network. For advanced network professionals, an integrated CLI is available for quick and direct access using familiar commands.
Even greater convenience and flexibility is provided by the UNMS app, which makes it possible to manage the EdgeRouter remotely from your mobile device.
Manage Your Network
DHCP Server Set up multiple DHCP servers to assign IP ranges in different subnets on the different interfaces. Easily control dynamic and static IP
addressing for your network devices.
Monitoring Tools Conveniently track network activity and devices from tools such as Ping, Trace, Discover, Packet Capture, and Log Monitor.
Secure Your Network
Firewall Policies Organize the rules you apply in the order you specify.
Firewall Groups Apply the policies to groups filtered by IP address, network address, or port number.
NAT Rules The EdgeRouter changes packet addressing based on your customized source and destination NAT rules.
Direct Traffic Flow
Interfaces Each port functions as an independent interface.
You can also configure Virtual Local Area Network (VLAN) interfaces for network segmentation.
Routing Configure static routes and dynamic routing protocols to effectively manage the routes used by the EdgeRouter.
Price/Performance Breakthrough
The EdgeRouter™ 6P offers next-generation price/performance value: up to 3.4 million packets per second processing with a line rate of up to 6 Gbps.
Versatile Design
The EdgeRouter 6P can be rack-mounted with the use of the EdgeRouter Rack Mount Kit, model ER-RMKIT (sold separately).
Centralized Management
The EdgeRouter 6P is supported and managed by UNMS™ (Ubiquiti® Network Management System), a comprehensive controller with an intuitive UI. A single control plane manages registered EdgeMAX® devices across multiple sites.
Specification:
Dimensions: 229 x 136.5 x 31.1 mm (9.02 x 5.37 x 1.22 in)
Weight: 730 g (1.61 lb)
Max. Power Consumption: 16 W (Excludes PoE Output)
Power: External AC Power Adapter, 60W (24V, 2.5A)
Power Input: 110 - 240VAC
Button: Reset
LEDs: Data Ports (Speed/Link/Activity), SFP Data Port (Link/Activity)
Networking Interfaces
Management:
(1) RJ45 Serial Port
(6) Ethernet Ports (Default eth0)
Networking:
(5) 10/100/1000 RJ45 Ports
(1) 1 Gbps SFP Port
Processor: 4-Core 1 GHz, MIPS64
System Memory: 1 GB DDR3 RAM
On-Board Flash Storage: 4 GB eMMC, 8 MB SPI NOR
Rack-Mountable: Yes
Operating Temperature: -10 to 50° C (14 to 122° F)
Operating Humidity: 10 - 90% Noncondensing
Certifications: CE, FCC, IC
PoE with 24VDC Power Adapter
PoE Interfaces: (5) 24V Passive PoE Ports, 2-pair (4, 5+; 7, 8-) and 4-pair
Passive PoE Max. Wattage Per Port: 24W (24V/1A, 4-pair)
Voltage Range Passive PoE: 24V
