UBIQUITI 5-Port PoE Managed Switch EdgeSwitch 5XP (ES-5XP)
5 Gigabit PoE Ports, 24V Configurable Passive PoE, EdgeSwitch XP Configuration Interface, Wall-Mountable
|Price exc. VAT:||Price inc. VAT:||For orders (total sum):|
Advanced Gigabit PoE Managed Switch
Introducing the Advanced Power over Ethernet Switches, EdgeSwitch™ XP from Ubiquiti Networks.
EdgeSwitch XP delivers reliable passive PoE and fast 10/100/1000 Mbps connectivity to attached Ubiquiti devices and other devices that support passive PoE.
To connect your PoE devices, simply enable PoE in the easy-touse EdgeSwitch XP Configuration Interface. Each port can be individually configured to provide PoE, so both PoE and non‑PoE devices can be connected.
EdgeSwitch XP is available in multiple versions to meet your deployment needs.
• EdgeSwitch 5XP is a cost‑effective, 5-port Gigabit switch with 24V PoE support.
• EdgeSwitch 8XP is an industrialstrength, 8-port Gigabit switch with 150 watts of power capable of powering 24V or 48V devices (Output voltage is controlled by the software).
• EdgeSwitch 16XP features dual EdgeSwitch 8XP systems in a rack‑mountable, 1U form factor with 300 watts of power supporting up to 16 devices.
Simplify Your Deployment
EdgeSwitch XP allows network architects to design cleaner, less cluttered deployments. For example, integrating one EdgeSwitch 8XP can eliminate the need for the following:
• 8 PoE adapters
• 8 power cords
• 8 power outlets
• 8 Ethernet patch cables
EdgeSwitch XP deployments increase efficiency and greatly reduce potential failure points – resulting in faster installations and less maintenance and troubleshooting.
Intuitive Configuration Interface
EdgeSwitch XP provides a user‑friendly configuration interface designed for efficient setup and control. Accessed via a secured management port and web browser, the EdgeSwitch XP Configuration Interface provides intuitive management with a virtual view of the ports, showing physical connectivity, speed, and PoE status.
EdgeSwitch XP is loaded with a variety of advanced features, including:
• Port monitoring
• System connection and management services
• Virtual Local Area Network (VLAN) configuration
• Spanning Tree Protocol (STP)/
Rapid Spanning Tree Protocol (RSTP)
• Jumbo Frame Support
• Ping Watchdog
• Configurable alerts
Dimensions: 197 x 87.5 x 27.3 mm
Weight: 250 g
Power Input: 24VDC, 2.5A Power Adapter (Included)
Max. Power Consumption: 60 W
PoE Out Voltage Range: 22-24VDC
Max. PoE Wattage Per Data Port: 11.5 W
ESD Rating: 24 kV Air / 24 kV Contact
PoE Method: Passive
USB Port: 2.0 Type A (Reserved for Future Use)
Processor: MIPS 24K, 400 MHz
System Memory: 64 MB
Code Storage: 8 MB
Certifications: CE, FCC, IC
Operating Temperature: -25 to 55°C (-13 to 131° F)
Operating Humidity: 90% Non-Condensing
PoE Configurable Per Port:
Management Port: N/A
Data Ports: Off/24V
LEDs Per Port:
Management Port: Power /Link/Activity
Data Ports: PoE, Speed/Link/Activity
Management Port: (1) 10/100 Ethernet Port
Data Ports: (5) 10/100/1000 Ethernet Ports
