UBIQUITI 24 Ports Gigabit Switch Pro Gen2 (USW-Pro-24)
24x Gigabit RJ45 ports | 2x SFP+ ports | Layer 3 Support | 1.3" Color Touchscreen Display
| Price exc. VAT: | Price inc. VAT: | For orders (total sum): |
| 300.96£ | 361.15£ | >0£ |
| 298.19£ | 357.83£ | >300£ |
| 295.43£ | 354.52£ | >1000£ |
Features:
Overview
Expand and power your network with the UniFi® Pro Switch, part of the Ubiquiti® UniFi Enterprise System. It is available in two models:
• USW-Pro-24 24 RJ45 ports with 2 SFP+ ports
• USW-Pro-48 48 RJ45 ports with 4 SFP+ ports
Fanless, Silent Cooling
The passive cooling design allows the UniFi Pro Switch to be located in any workspace.
Fiber Connectivity
SFP+ ports enable high-capacity uplinks of up to 10 Gbps, so you can directly connect to a high-performance storage server or deploy a long-distance uplink to another switch.
Layer 3 Features
In addition to Layer 2 switching protocols and features, the UniFi Pro Switch offers Layer 3 capabilities, such as inter‑VLAN routing, static routing, and DHCP server functionality.
Switching Performance
The UniFi Pro Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.
Power Supply Redundancy
The UniFi Pro Switch supports our PSU failover system, the UniFi SmartPower RPS, model USP-RPS. If the internal power supply unit fails, the proprietary USP RPS interface acts to provide redundant power for backup.
Features
- (24) Gigabit RJ45 ports
- (2) 10G SFP+ ports
- Layer 2 and Layer 3 features
- UniFi SmartPower RPS DC input
- Near-silent cooling
- 1.3" touchscreen display
- Managed by UniFi Network Controller
Specification:
| Dimensions | 442.4 x 285.4 x 43.7 mm (17.42 x 11.24 x 1.72") |
| Weight With Brackets |
3.50 kg (7.72 lb) 3.59 kg (7.92 lb) |
| Interfaces Networking Management |
(24) 10/100/1000 RJ45 Ports (2) 1/10G SFP+ Ethernet Ports Ethernet In-Band |
| Total Non-Blocking Throughput | 44 Gbps |
| Switching Capacity | 88 Gbps |
| Forwarding Rate | 65.472 Mpps |
| Power Method Universal Input USP RPS DC Input |
100-240VAC, 50/60 Hz 11.5VDC, 2.61A |
| Power Supply | AC/DC, Internal, 36W |
| Voltage Range | 100 to 240VAC |
| Max Power Consumption | 30W |
| LEDs RJ45 Data Ports SFP+ Data Ports |
Speed/Link/Activity Link/Activity |
| ESD/EMP Protection | Air: ± 16 kV, Contact: ± 12 kV |
| Shock and Vibration | ETSI300-019-1.4 Standard |
| Operating Temperature | -5 to 45° C (23 to 113° F) |
| Operating Humidity | 10 - 90% Noncondensing |
| Certifications | CE, FCC, IC |
