TELTONIKA Small and smart tracker with Bluetooth and internal backup battery (FMB920)

Order code: FMB920
Quick code: #1667

Bluetooth for exchanging data over short distances, Allows device to work without external power source, Crash detection functionality working according accelerometer data, Allows reading CAN bus data from vehicle ECU via Bluetooth

Price exc. VAT: Price inc. VAT: For orders (total sum):
28.14£ 33.77£ >0£
27.96£ 33.55£ >300£
27.91£ 33.49£ >1000£


Teltonika FMB920 is compact and smart tracker with Bluetooth connectivity, internal High Gain GNSS and GSM antennas and integrated backup battery. FMB920 is designed for light vehicles tracking in applications like insurance telematics, rental cars, recovery of stolen cars, public safety services, delivery transport, taxi and much more. Inputs/outputs extend device usage scenarios. Digital input can be used for ignition, door or alarm button status monitoring. Vehicle remote immobilizing may be achieved using FMB920 digital output.


Name: TM2500

Receiver: 33 channel
Tracking sensitivity: -165 dBM
Accuracy: < 3 m
Hot start: < 1 s
Warm start: < 25 s
Cold start: < 35 s

Technology: GSM
2G bands: Quad-band 850 / 900 / 1800 / 1900 MHz
Data transfer: GPRS Multi-Slot Class 12 (up to 240 kbps), GPRS Mobile Station Class B
Data support: SMS (text/data)

Input voltage range: 6 - 30 V DC with overvoltage protection
Back-up battery: 170 mAh Li-Ion battery (0.63 Wh)

Power consumption:
   At 12V < 2 mA (Ultra Deep Sleep)
   At 12V < 4 mA (Deep Sleep)
   At 12V < 5 mA (Online Sleep)
   At 12V < 6 mA (GPS Sleep)
   At 12V < 25 mA (nominal)

Specification: 4.0 + LE
Supported peripherals: Temperature and Humidity sensor, Headset, OBDII dongle, Inateck Barcode Scanner

Digital Inputs: 1
Digital Outputs: 1
Analog Inputs: 1
GNSS antenna: Internal High Gain
GSM antenna: Internal High Gain
USB: 2.0 Micro-USB
LED indication: 2 status LED lights
SIM: Micro-SIM
Memory: 128MB internal flash memory

Physical specification
Dimensions: 79 x 43 x 12 mm (L x W x H)
Weight: 54 g

Operating environment
Operating temperature (without battery): -40 °C to +85 °C
Storage temperature (without battery): -40 °C to +85 °C
Operating humidity: 5% to 95% non-condensing
Ingress Protection Rating: IP54
Battery charge temperature: 0 °C to +45 °C
Battery discharge temperature: -20 °C to +60 °C

Battery storage temperature:
   -20 °C to +45 °C for 1 month
   -20 °C to +35 °C for 6 months

Sensors: Accelerometer
Scenarios: Green Driving, Over Speeding detection, Jamming detection, GNSS Fuel Counter, DOUT Control Via Call, Excessive Idling detection, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip
Sleep modes: GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep
Configuration and firmware update: FOTA Web, FOTA, Teltonika Configurator (USB, Bluetooth), FMBT mobile application (Configuration)
SMS: Configuration, Events, DOUT control, Debug
GPRS commands: Configuration, DOUT control, Debug
Time Synchronization: GPS, NITZ, NTP
Fuel monitoring: LLS (Analog), ODBII dongle
Ignition detection: Digital Input 1, Accelerometer, External Power Voltage, Engine RPM (OBDII dongle)

Certification & Approvals
Regulatory: CE/RED, E-Mark, EAC, RoHS, MTBF, REACH
