MIKROTIK Weatherproof Wi‑Fi 6 Access Point with High-Speed CAT7 LTE modem, wAP ax LTE7 kit (wAPGR-5HaxD2HaxD&R11e-LTE7)
Cat.7 LTE modem (DL up to 300 Mbps, UP up to 100 Mbps) | Dual-band Wi-Fi 6 (2.4/5 GHz) | 2x Gigabit LAN ports | 1x MiniPCI-e slot | PoE-In & DC jack | Router OS (Licence level 4)
| Price exc. VAT: | Price inc. VAT: | For orders (total sum): |
| 108.86£ | 130.63£ | >0£ |
| 107.93£ | 129.52£ | >300£ |
| 106.06£ | 127.27£ | >1000£ |
Features:
The new wAP LTE7 kit is an evolution of the popular wAP ac LTE6. Now – with Wi-Fi 6, CAT7 LTE, a stronger ARM platform, and improved antenna gain. The unit comes in an improved next-gen IP66 weatherproof enclosure.
wAP ax LTE7 kit brings fast and reliable Wi-Fi 6 to your countryside getaway or any other challenging environment – like a rural gas station or a bus stop. The updated enclosure enhances durability even further and features a concealed anti-vandal screw behind the MikroTik logo for added security.
Now upgraded with a CAT7 LTE modem, doubled upload speeds, and a more powerful ARM platform, this generation raises the performance bar without changing what people love about wAP or raising the price.
A mighty dual-band, dual-chain (2x2 MIMO) radio ensures strong wireless coverage across your home, yard, or business premises – enhanced by higher antenna gain and a redesigned LTE antenna system for improved signal quality, greater range, and better stability in challenging environments.
Specification:
Product code: wAPGR-5HaxD2HaxD&R11e-LTE7
Architecture: ARM 32bit
CPU: IPQ-5010
CPU core count: 2
CPU nominal frequency: 800 MHz
CPU Threads count: 2
RouterOS license: 4
Operating System: RouterOS v7
Size of RAM: 256 MB
Storage size: 128 MB
Storage type: NAND
MTBF: Approximately 200'000 hours at 25C
Tested ambient temperature: -30°C to 70°C
Powering
Number of DC inputs: 2 (DC jack, PoE-IN)
DC jack input Voltage: 12-57 V
Max power consumption: 13 W
PoE in: 802.3af/at
Cooling type: Passive
PoE in input Voltage: 18-57 V
Mobile
3G Category: R8 (DL: 42.2 Mbps; UL: 5.76 Mbps)
3G bands:
1 (2100 MHz)
3 (1800 MHz)
5 (850 MHz)
8 (900 MHz)
LTE Category: 7 (DL: 300 Mbps; UL: 100 Mbps)
MIMO: DL 2x2
MIMO UL 1x1
LTE FDD bands:
1 (2100 MHz)
3 (1800 MHz)
5 (850 MHz)
7 (2600 MHz)
8 (900 MHz)
20 (800 MHz)
28 (700 MHz)
32 (1500 MHz)
LTE TDD bands:
38 (2600 MHz)
40 (2300 MHz)
41 (2500 MHz)
TAC: 35312597
Wireless specifications
Wireless 2.4 GHz Max data rate: 574 Mbit/s
Wireless 2.4 GHz Number of chains: 2
Wireless 2.4 GHz standards: 802.11b/g/n/ax
Antenna gain dBi for 2.4 GHz: 6.9
Wireless 2.4 GHz chip model: IPQ-5010
Wireless 2.4 GHz generation: Wi-Fi 6
Wireless 5 GHz Max data rate: 1200 Mbit/s
Wireless 5 GHz Number of chains: 2
Wireless 5 GHz standards: 802.11a/n/ac/ax
Antenna gain dBi for 5 GHz: 7
Wireless 5 GHz chip model: QCN-6102
Wireless 5 GHz generation: Wi-Fi 6
Ethernet
10/100/1000 Ethernet ports: 2
Peripherals
Number of SIM slots: 1 Modem (Micro SIM)
MiniPCI-e slots: 1
Other
CPU temperature monitor: Yes
PCB temperature monitor: Yes
Voltage Monitor: Yes
Certification & Approvals
Certification: CE, EAC, ROHS
IP: 66
