ALFA NETWORK WiFi 6/6E (802.11ax) 2x2 Tri-band 2.4 GHz / 5 GHz / 6 GHz and Bluetooth v5.2 high-performance USB adapter (AWUS036AXM)
2x RP-SMA external antenna connectors | 2x High-gain detachable dipole antennas | 1x USB 3.2 Gen.1 port | Wi-Fi Standards 802.11a/b/g/n/ac/ax (WiFi 6/6E) | 2.4 GHz: up to 600 Mbps, 5 GHz: up to 1200 Mbps, 6 GHz: up to 1200 Mbps | Bluetooth V.5.2
| Price exc. VAT: | Price inc. VAT: | For orders (total sum): |
| 25.77£ | 30.92£ | >0£ |
| 25.37£ | 30.44£ | >300£ |
| 24.98£ | 29.98£ | >1000£ |
Features:
AWUS036AXM supports super speeds up to 3000 Mbps (2.4 GHz 600 Mbps, 5 GHz 1200 Mbps, and 6 GHz 1200 Mbps) when used with a compatible WiFi 6E router (there are various stream models of WiFi 6E routers, 800-1200 Mbps will be a more common speed with most routers) and with 2x RP-SMA antenna connector allows changing the higher gain antenna to increase the connection distance. AWUS036AXM also supports the latest Bluetooth v5.2, which provides higher-quality audio over Bluetooth for headphones or speakers.
- MT7921AUN WiFi 6/6E + BT 5.2 combo chip
- USB-A connector support USB 3.2 GEN 1
- 2x RP-SMA external antenna connector
- 2x High-gain detachable dipole antenna
- Integrated BT antenna
- LED indicator
Specification:
|
Chipset |
MediaTek MT7921AUN |
|
IEEE 802.11 standards |
a/b/g/n/ac/ax |
|
Bluetooth |
5.2 |
|
Frequency
|
2.4 GHz 5 GHz 6 GHz |
|
Data rate
|
2.4 GHz up to 600 Mbps 5 GHz up to 1200 Mbps 6 GHz up to 1200 Mbps |
|
USB connector |
USB 3.2 Gen 1 Type-A |
|
WiFi Antenna
|
2x RP-SMA antenna connector with 2x dual-band high-gain dipole antenna |
|
BT Antenna |
Integrated antenna |
|
Power consumption |
2.7 Watts (max.) |
|
Dimensions |
87.4 x 28.5 x 12 mm (3.44 x 1.13 x 0.47 inches) |
|
Operating temperature |
-20° C - 70° C (-4° F - 158° F) |
|
Operation voltage |
5 V |
|
OS support |
Windows 10/11 & Linux |
