ALFA NETWORK Outdoor 4G/LTE Cat. 4 Global USB Modem, N female (Tube-U4Gv2)

MPN: Tube-U4Gv2

Order code: Tube-U4Gv2

Quick code: #3496

150/50Mbit/s | 1x mini-USB 2.0 | 1x SIM slot |High-gain 4G/LTE omni antenna | N-female connector | IP66 | Windows OS supported | 5m outdoor USB cable

Price exc. VAT:	Price inc. VAT:	For orders (total sum):
86.48£	103.78£	>0£
85.14£	102.17£	>300£
83.81£	100.57£	>1000£
Qty:

Features:

ALFA Tube-U4Gv2 is a weatherproof 4G modem with USB port and integrated SIM card slot for data SIM card of your preferred provider. Simply connect the supplied 4G antenna or any other antenna with a suitable antenna connector to the antenna port (N female) of the Tube 4G. The weatherproof enclosure allows outdoor installation. Optionally, the Tube U4G v2 can be combined very well with the ALFA R36AH.

With the Alfa Tube-U4Gv2 Long Range Outdoor USB-Modem with N-Type Connector you have always and everywhere access via Mobile (4G 3G LTE UMTS GSM) Internet access. Due to the weatherproof design, the USB modem is the ideal companion for camping holidays and on boats. But even truck drivers love the fast construction on rest areas or as solid construction on the truck. It's that easy to access the internet.

Specification:

Parameter	Value
Supported Bands	LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28 LTE-TDD: B38/B39/B40/B41 WCDMA: B1/B2/B4/B5/B6/B8/B19 GSM: B2/B3/B5/B8
Region	Global
Data Rates	LTE: LTE-FDD: Max 150Mbps (DL)/Max 50Mbps (UL) LTE-TDD: Max 130Mbps (DL)/Max 30Mbps (UL) UMTS: DC-HSDPA: Max 42Mbps (DL) HSUPA: Max 5.76Mbps (UL) WCDMA: Max 384Kbps (DL)/Max 384Kbps (UL) GSM: EDGE: Max 296Kbps (DL)/Max 236.8Kbps (UL) GPRS: Max 107Kbps (DL)/Max 85.6Kbps (UL)
Interfaces	Mini-USB 2.0 Standard 6 PIN SIM card
Antenna Connector	N type female
Antenna	High-gain 4G/LTE Omni Antenna
LED Indicator	Power/Connection
Waterproof IP rate	IP66
Supported System	Windows, Linux
Temperature Range	-40°C ~ 80°C
Storage Humidity	5% ~ 98% (Non-condensing)
Dimensions	185 x 47 mm
Weight	135 g
