24V (1A) Gigabit PoE adapter, UK type plug (POE-24V-24W-G-UK)

Order code: POE-24V-24W-G-UK
Quick code: #1510

UK type plug 24V 1A DC POE Gigabit adapter (24W), suitable for most Mikrotik, Ubiquiti, Ligowave and other products

Price exc. VAT: Price inc. VAT: For orders (total sum):
2.89£ 3.47£ >0£
2.85£ 3.42£ >300£
2.80£ 3.36£ >1000£


This product is a Power Over Ethernet Injector (AC TO DC power transfer device), it can provide for a 24W (24V DC 1000mA)single DC output with constant voltage source, it inserts DC Voltage
into Cat.5 cable allowing the cable between the injector(ZCC0241000UK) and POE Ready Device to transfer data and power simultaneously. The maximum distance between the injector and POE Ready Device is 100 meters max. The poe injector (ZCC0241000UK) provides 10/100/1000Mbps Gigabit Ethernet connection ability.

Efficiency Over 85%
Over-Voltage Protective Installation
Short-circuit Protective Installation
Protection Type: Auto-Recover


Input Voltage (AC): 100- 240Vac (nominal)
Input Frequency Range: 47 Hz(min) ~ 63 Hz(max)
Output Voltage (DC): 24 V (22.8-25.2)
Output Rating: 1A (24W)
Operating Temperature: -10°C ~ +40°C
Storage Temperature: -30°C ~ +80°C
Operating Humidity: 10%~95% non-condensing
Storage Humidity: 10%~95% non-condensing
Weight: 95 g
Certification: CE
